Complete Benteler Glass Processing Line (Fully Reconditioned in 2012)

2007 Benteler (max glass size 6000×2800) fully reconditioned in 2012.

Includes:

Tilting table (6000mm X 2800mm)

• Length 6000 mm;
• Width 2800 mm;
• Distance between rollers 250 mm;
• Roller diameter 75 mm.

CNC Machining Centre Glass (Grinding, Milling, Polishing) glass thickness 2-19mm

• Transport section length 8000 mm;
• Transport section width 5100 mm;
• Machine frame width 5900 mm;
• Machine frame height 1800 mm;
• Operational zone height 1030 mm;
• Max glass weight 1000 kg;
• Grinding speed 0-20 m/min;
• Polishing speed 0-20 m/min;
• Milling speed 0-1,5 m/min.

Drilling Spindle (X direction 160mm Y direction 115mm)

• Drilling diameter 85 mm;
• X-direction 160mm, Y-direction 115 mm.

Machining Centre Outlet

• Length 6000 mm;
• Width 2800 mm.

Washing Machine

• Glass dimensions 6000×2800 mm;
• Glass thickness 1.5-19 mm;
• Pumping pressure 10 bar.

Discharge tilting table

• Length 6000 mm;
• Width 2800 mm.

Tools amount

• Milling tools – 5 pieces;
• Grinding tools – 10 pieces;
• Polishing tools – 15 pieces;
• Drilling tools – 10 pieces.
