2012 Complete Solar Glass Line Tempering/Processing/Cutting

Solar Glass Complete Plant Tempering Furnace Glass Processing Glass Cutting

  • Manufacturer: Hegla/Benteler/Glaston
  • Year: 2012
  • Location: Europe
  • Cathegory: Glass Processing Machines
previous arrow
next arrow
ArrowArrow
Slider

Description

The whole production line consists of the following pieces of equipment: ( „Layout 1 – the whole production line )

Includes:

  1. Glass cutting system with automatic breakout for X and Y plus conveyors ( Type: Galactic 7033 R ; Make: HEGLA GmbH and Co.KG ; Year: 2012 )
  2. Grinding and drilling line. ( Type: grinding machine, drilling machine ,washing machine ; Make: Benteler Maschinenbau GmbH; Year: 2012 )
  3. 3. Glaston continuous horizontal tempering line. ( Type : CHF 2000 ProTM 15×27 – PT2.85; Make: Glaston Finland OY; Year: 2012)

Ad.1 Glass cutting system with automatic breakout for X and Y plus conveyors.
Machine description: ( „ Layout 1,1 – cutting line” )

  1. Two-side loading station type: BBS 7033
  2. Glass cutting table with glass positioning conveyor type: Optimax Galactic 7033 R
  3. Belt conveyor type: TWK 7533
  4. Glass breakout machine type:STB II 33
  5. Belt conveyor type: TW 3333
  6. Wheel conveyor with turntable.
  7. Belt conveyor type: TWK 3830
  8. Glass breakout machine type: STB 30
  9. Belt conveyor type:TW 2030
  10. Wheel conveyor with turntable
  11. 90 degrees corner transfer belt/wheel conveyor E 3025
  12. Unloading table

Machine data:

    • Glass thickness range: 3 – 6 mm
    • Glass sizes ( row material): min. 3200 x 2000 mm,
      maks. 7000 x 3300 mm
    • Glass sizes ( ready product): min. 500 x 500 mm
      maks. 1300 x 2500 mm

Ad.2 Grinding and drilling machine.
Machine description: ( „ Layout 1,2 – grinding and drilling line” )

  1. Horizontal conveyors: B1.010, B1.020, B1.040, B1.050, B1070, B1 080, B1.095, B1.110, B1.120, B1.130, B1.140, B1.150
  2. Grinding machine ( egdes and corners): B1.030, B1.060
  3. Drilling machine: B1.090
  4. Washing machine type:E-Save1300 – B1.100

Machine data

    • Glass thickness range: 2 – 6 mm
    • Glass sizes: min. 450 x 400 mm
      max. 2500 x 1300 mm
    • Maximum dimension tolerance before grinding: ±0,2 mm
    • Min./max. grinding speed: 3 – 16 m/min
    • Max. grinding speed with corner grinding: 12 m/min
    • Profile of grinding: C lub K w zależności od narzędzia
    • Min. loss of each side: 0,3 mm
    • Corner grinding with profile C: 2 mm ± 1mm, 45°
    • Hole position accuracy: ±0,3mm/1500 mm
    • Maximum feed rate of the drilling spindle: 7000 mm/min
    • Minimum feed rate of the drilling spindle: 15 mm/min
    • Speed of the drilling spindle: 900 – 3300 min-1
    • Transport speed of the washing machine: 3 – 13 m/min

Ad.3 . Glaston continuous horizontal tempering line
Machine description: ( „ Layout 1,3 – tempering furnace )

      1. Loading table
      2. Tempering furnacce
      3. Quench, chiller and cooling section
      4. Unloading table
      5. Sound absorbing chamber

Machine data:

      • Process: tempering Glass according EN 12150:2000
      • Glass thickness range: 2.85 – 6 mm
      • Glass type: clear float/ low iron glass
      • Loading area: 1500 x 2500 mm
      • Minimum glass size: 100 x 500 mm
      • Maximum glass size:

– glass thickness: 2.85 – 2.99 – mm 1300 x 2400 mm
– glass thickness: 3.00 – 3.79 mm – 1300 x 2500 mm
– glass thickness: 3.80 and over – 1500 x 2500 mm

Excellent Working Condition
